Air Filter Assembly.

The Concept

The Air Filter assembly needed  to have a Rat-Rod look.

Not be too big and clumsy,

 and at the same time do its job - clean the air.

We also wanted it to bolt directly onto the Electric Supercharger as

 this could save some space.

Back to the mighty EvilBay to find a 66mm filter.

66mm Throat on each side of the Supercharger.

This is what we found!

Dress up your engine with an 4 inch round RPC Chrome air cleaner with paper element. Fits 1 & 2 barrel Carburetors with 2-5/8" Neck. Mounting stud included.

 Specs:

Diameter (in): 4 in.
Material: Aluminium
Finish: Chromed
Height (in): 2-7/8 in.
Air Cleaner Filter: White paper
Mounting stud Included: Yes

The Build

First step - modify the stock air filter assembly.

Before and after - all excess material removed.

Next we need to modify supercharger end of the pipe-work.

We used blue silicone hose to mate the supercharger to the air pipe.

The air filter has then been clamped on to the supercharger.

A large turbo charger pressure clamp has been used here.
